Steel wire rod

Product Item : 1
Category： Steel wire rod
Hot rolled
steel
wire rod
steel wire
INQUIRY EMAIL

Premium quality steel wire rod

Dia 5.5-20mm

Grade: 35-90#

Standard: GB, JIS, ASTM, DIN

LF & VD forge;ISO&TUV approve

Used to make steel nail, mechanical spare parts. The high carbon steel wire coil is used to make steel wire rope for different usage, spring steel wire, steel core Al strands, galvanized steel wire, galvanized steel strands, prestressing steel wire.

Grade	Dia(mm)	Chemical Composition (%)
Grade	Dia(mm)	C	Si	Mn	P	S	Ni	Cr	Cu
35	5.5-20	0.32-0.39	0.17-0.37	0.50-0.80	≤0.035	≤0.035	≤0.30	≤0.25	≤0.25
40		0.37-0.44	0.17-0.37	0.50-0.80	≤0.035	≤0.035	≤0.30	≤0.25	≤0.25
45		0.42-0.50	0.17-0.37	0.50-0.80	≤0.035	≤0.035	≤0.30	≤0.25	≤0.25
50		0.52-0.60	0.17-0.37	0.50-0.80	≤0.035	≤0.035	≤0.30	≤0.25	≤0.25
60		0.57-0.65	0.17-0.37	0.50-0.80	≤0.035	≤0.035	≤0.30	≤0.25	≤0.25
70		0.67-0.75	0.17-0.37	0.50-0.80	≤0.035	≤0.035	≤0.30	≤0.25	≤0.25
80		0.77-0.85	0.17-0.37	0.50-0.80	≤0.035	≤0.035	≤0.30	≤0.25	≤0.25
85		0.82-0.90	0.17-0.37	0.50-0.80	≤0.035	≤0.035	≤0.30	≤0.25	≤0.25

Low carbon steel wire rod SAE1006B, SAE1008B, SAE1018B

1.Diameter:5.5mm-20mm

2.Material:SAE1006-SAE1018

3.Coil weight:1.8-2.1ton

4.Applicant: wire drawing,welding electrode, nail

Grade	Chemical Composition(%)
	C	Mn	Si	S	P	B
SAE1006B	0.03~O.07	≤0.32	≤0.30	≤0.045	≤0.040	>0.0008
	Mechanical properties
	Yield strength(N/mm2)		Tensile strength(N/mm2)		Elongation(%)
	250-280		350-380		≥32
Grade	Chemical Composition(%)
	C	Mn	Si	S	P	B
SAE1008B	0.10max	0.3~O.50	≤0.15	≤0.050	≤0.040	>0.0008
	Mechanical properties
	Yield strength(N/mm2)		Tensile strength(N/mm2)		Elongation(%)
	≥195		315-430		≥30
Grade	Chemical Composition(%)
	C	Mn	Si	S	P	B
SAE1018B	0.15-0.20	0.6~O.90	0.15-0.35	0.060max	0.040 max	0.0008-0.004
	Mechanical properties
	Tensile strength(N/mm2)				Elongation(%)
	440-510				≥30
